Name: GPSアンテナ GA150
SKU: 302785

GPSアンテナ GA150

$ 47.82

$ 62.17

Save: $

Unavailable

Please select combo product attributes

The combo subtotal is $,SAVE$

GA150 GPS Receiver Physical Specifications

DimensionsDiameter: 95 mm (3.7 in.) | Height: 30 mm (1.2 in.) | Height (including pole mount adaptor): 62 mm (2.5 in.)

WeightBoxed weight 0.74 Kg (1.6 lbs) | Unboxed weight (including cable): 0.5 Kg (1.1 lbs)

Environmental Specifications

Operating Temperature0°C to 55°C ( 32°F to 131°F)

Storage Temperature–30°C to 70°C (-22°F to 158°F)

Relative Humidity95%

Waterproof RatingIPX6 and IPX7

GA150 - What's in the box?

The GA150 is available with the features, options, and accessories described below.
Refer to the packing list enclosed with your GA150 shipment to determine the actual contents of your package.

GA150 Antenna (The antenna is supplied with a fitted 10m (33 ft.) cable for connection to your MFD.)
GA150 Mounting Gasket
Pole Mount Adapter
2x Thumb Nuts
2x Studs
2x Screws
Document Pack

Connections

Follow the steps below to connect the GA150 external antenna.

Fully insert the antenna’s cable connector into the GA150 connector on the rear of your display.
Turn the locking collar clockwise until TIGHT.
Push to protective boot over the connection on the back of the display.
Use the supplied cable tie to secure the protective boot over the connection.
